Ant 1000-P Russian Tracked Unmanned Ground Vehicle (UGV)
Ant 1000-P
Unmanned Ground Vehicle (UGV)
Other
Basic Information
Name
Ant 1000-P Russian Tracked Unmanned Ground Vehicle (UGV)
Designation
Ant 1000-P
Alternate Designation
Ant 1000-P
Equipment Type
Unmanned Ground Vehicle (UGV)
Manufacturer
Kovrov Electromechanical Plant (KEMZ)
Date of Introduction
2015
Description
The Ant 1000-P Russian Tracked Unmanned Ground Vehicle (UGV) can be used in various configurations including combat and loader. In its loader configuration, the Ant 1000-P can be used for digging narrow trenches, drill holes in the ground as well as loading/unloading.
Ground Specifications
Engine
Diesel
Max Speed
12.0 km/h
System
Alternative Designation
Ant 1000-P
Type
Unmanned Ground Vehicle (UGV)
Manufacturer
Kovrov Electromechanical Plant (KEMZ)
Configuration
Tracked
Crew
Unmanned
Operator
The Ant 1000-P's control unit is housed in a ruggedised case and the operator is provided with a 17-inch monitor with a resolution of 1,280 × 1,024, and controls the system via two joysticks.
Cameras
The vehicle features four cameras (one of which is a pan-tilt-zoom (PTZ)).
Payload Capacity
1,000 kg
Note
In its loader configuration, the Ant 1000-P can be used for digging narrow trenches, drill holes in the ground as well as loading/unloading.
Dimensions
Length
3.61 m
Width
1.99 m
Height
1.91 m
Weight, Combat
3,500 kg
Automotive
Engine Name
INA
Engine Type
Diesel
Engine Power
INA
Amphibious
No
Maximum Speed
12 km/h
Operating Range
2,000 m
Endurance
INA
Communications
Note
The Ant-1000P can be remotely controlled out to a range of 2,000 m.
Main Weapon System
Remote Weapon Station (RWS)
The armed version of the Ant 1000-P is fitted with the Arbalet-DM (named after a medieval crossbow) remote weapon station (RWS). The RWS is equipped with a 7.62 mm machine gun.
Elevation
–20° to 70°
Traverse
360°
Basic Load
750 Rounds
Protection
Armor
INA
Applique Armor
INA
Smoke Equipment
4 x smoke grenade launchers are fitted to the front of the vehicle.
Details
Country of Origin
Russia
Category
Unmanned Ground Vehicles (UGV)
Land > Unmanned Ground Vehicles (UGV)
Filter Label
A
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
3.61 m
Width
1.99 m
Height
1.91 m
Weight
3500 kg
Operators (1)
Russia
