Hunter RSVK-M2 Ukrainian 6x6 Unmanned Ground Vehicles (UGV)
Hunter RSVK-M2
Unmanned Ground Vehicle (UGV)
Other
Basic Information
Name
Hunter RSVK-M2 Ukrainian 6x6 Unmanned Ground Vehicles (UGV)
Designation
Hunter RSVK-M2
Alternate Designation
Hunter RSVK-M2
Equipment Type
Unmanned Ground Vehicle (UGV)
Manufacturer
Robotics Design Bureau
Date of Introduction
2015
Description
The Hunter RSVK-M2 Ukrainian 6x6 Unmanned Ground Vehicles (UGV) is designed to be a universal platform. The vehicle has been shown in its combat role, where it is capable of mounting a number of weapons.
Ground Specifications
Engine
Battery
Max Speed
30.0 km/h
System
Alternative Designation
Hunter RSVK-M2
Type
Unmanned Ground Vehicle (UGV)
Manufacturer
Robotics Design Bureau
Configuration
6x6
Crew
Unmanned
Operator
An operator can control the platform via a ruggedized, briefcase style, portable control unit.
Sensors
The company has also developed its own sighting system for the UGV called the (приладом наведення, ПН) guidance device. The guidance unit can identify objects at a distance of up to 600 m and also detect and fire out to a distance of up to 750 m.
Dimensions
Length
2.00 m
Width
1.25 m
Height
0.70 m
Weight, Empty
110 kg
Weight, Combat
410 kg
Automotive
Engine Name
INA
Engine Type
Battery
Engine Power
INA
Amphibious
No
Maximum Speed
30 km/h
Standard Speed
8 km/h
Operating Range
15–20 km on a single charge, depending on the terrain.
Endurance
In monitoring mode, the Hunter RSVK-M2 Ukrainian 6x6 Unmanned Ground Vehicles (UGV) can monitor around the clock without recharging for 2–3 days.
Communications
Note
An operator can control the platform and use a video signal up to a distance of 2 km using a protected channel that safeguards against jamming.
Main Weapon System
Note
Weapons that can be used with the Hunter RSVK-M2 Ukrainian 6x6 Unmanned Ground Vehicles (UGV) include the PKT 7.62 mm machine gun (MG), the NSV 12.7 mm MG, the AG-17A automatic grenade launcher (AGL), and anti-tank guided missiles (ATGM).
Protection
Armor
INA
Applique Armor
INA
Details
Country of Origin
Ukraine
Category
Unmanned Ground Vehicles (UGV)
Land > Unmanned Ground Vehicles (UGV)
Filter Label
H
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
2 m
Width
1.25 m
Height
0.7 m
Weight
410 kg
Operators (1)
Ukraine
