Supercam S450 Russian Unmanned Aerial Vehicle (UAV)

Supercam S450

Tactical Unmanned Aerial Vehicle (UAV)
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
Supercam S450 Russian Unmanned Aerial Vehicle (UAV)
Designation
Supercam S450
Alternate Designation
Supercam S450
Equipment Type
Tactical Unmanned Aerial Vehicle (UAV)
Manufacturer
Supercam Unmanned Systems Group
Date of Introduction
2020
Description

The Supercam S450 Russian Unmanned Aerial Vehicle (UAV) can fly for up to 6 hours and transmit data over a range of 100 km in real-time. The unmanned aircraft can perform missions of ensuring the safety and control of strategic facilities, allows determining the target coordinates, and provides decision-making on adjusting the actions of ground services. Due to the built-in inertial system (INS), which is integrated into each Supercam UAV, the aircraft is able to continue its flight in the absence of signals from satellite navigation systems. A wide range of payloads and useful equipment can be installed onboard the aircraft. Despite the UAV wingspan of 4.5 m, the Supercam S450 design with detachable wing panels provides the convenience of its transportation by 2-3 people.

Air & Air Defense Specifications
Engine Battery
Max Speed 120.0 km/h
Endurance 7.00 hrs
Wingspan 4.50 m
System
Alternate Designation Supercam S450
Type Unmanned Aerial Vehicle (UAV)
Manufacturer Supercam Unmanned Systems Group
Autonomy automatic or semi-automatic
Crew Unmanned
Radio Link Range 110 km
Video Transmission Range 100 km
Payload Options - 20/24/42/60 MP photo camera with the ability to be mounted on the azimuth stabilized platform - HD video camera with min 30х optical zoom integrated with thermal imaging camera with 16x digital zoom and a laser target marker - Multispectral camera - Airborne radiation sensor - Laser gas analyzer - Laser scanner - Voice announcement system
Deployment Time 15 min
Launching System pneumatic catapult
Recovery System parachute with cords release system and air dampers in the wing panels
Operational Temperature -40°С to +45°С
Accessories - Automatic target tracking module - Dual (triple) system, dual-frequency geodetic receiver - Video link for digital broadband transmission within a range of up to 100 km - Radio link of telemetry and control with the ability of FHSS operation
Dimensions
Length INA
Wingspan 4.5 m
Height INA
Maximum Takeoff Weight 29 kg
Automotive
Engine Name INA
Engine Type Battery
Engine Power INA
Maximum Speed 120 km/h
Cruising Speed INA
Operational Height 150 - 5000 m
Maximum Distance 450 km
Maximum Windspeed 15 m/s
Endurance 7 hours
Details
Country of Origin Russia
Category UAVs
Air > UAVs
Filter Label
S
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
Width
Height
Weight
29 kg
Operators (1)
Russia
