TARES III 16TTC1 Saudi 4x4 Mine Resistant Ambush Protected (MRAP)
TARES III 16TTC1
Mine-Resistant Ambush Protected (MRAP)
Other
Basic Information
Name
TARES III 16TTC1 Saudi 4x4 Mine Resistant Ambush Protected (MRAP)
Designation
TARES III 16TTC1
Alternate Designation
TARES III 16TTC1
Equipment Type
Mine-Resistant Ambush Protected (MRAP)
Manufacturer
ERAF
Date of Introduction
2026
Description
The TARES III 16TTC1 Saudi 4x4 Mine Resistant Ambush Protected (MRAP) combines STANAG Level III protection, high off‑road mobility, and configurable mission systems to support defense and internal security operations. The vehicle is explicitly categorized as an MRAP and is intended for use by regular armed forces, national guard units, and paramilitary formations conducting border security and territorial control missions.
Ground Specifications
Crew
3
Mobility Type
Wheeled (4x4)
Engine
Diesel (360 hp)
NBC Protection
Yes
Max Speed
110.0 km/h
Range
600.0 km
System
Alternative Designation
TARES III 16TTC1
Type
Mine Resistant Ambush Protected (MRAP)
Manufacturer
ERAF
Configuration
4x4
Crew
3 ea
Passengers
8 ea
Payload Capacity
8,000 kg
Dimensions
Length
6,910 mm (3625 mm with turret)
Width
2,820 mm
Height
2,635 mm
Weight, Combat
16,000 kg
Automotive
Engine Name
Cummins ISB 6.7 HPRC
Engine Type
Diesel
Engine Power
360 hp @ 2500 rpm
Fuel Tank Capacity
265 liters
Transmission
Allison fully automatic SP series, 6F / 1R
Maximum Range
600 km
Maximum Speed
110 km/h
Amphibious
No
Gradient
60%
Side Slope
30%
Vertical Step
INA
Trench
INA
Fording
INA
Main Weapon System
Note
The vehicle layout supports the integration of roof-mounted weapon systems and turrets without altering the core hull dimensions. At WDS 2026, ERAF also displayed turret systems including a 25 mm turret of South African origin (designed by Comenius, now produced by ERAF in Saudi Arabia under a technology transfer arrangement) mounted on the 19TC1.
Protection
Armor
The Tares III-16TC1 provides STANAG 4569 Level III ballistic protection. This is one level below the 19TC1's Level IV, but sufficient for a wide range of threat environments. The vehicle's MRAP designation reflects its design emphasis on countering mines and improvised explosive devices (IEDs). Interior crew protection measures include blast-attenuating seats designed to mitigate underbody blast effects. Unlike the monocoque V-hull structure of the 19TC1 and 10TC1, the 16TC1 uses a chassis-based architecture, which contributes to its lower kerb mass while maintaining MRAP-level protection standards.
Applique Armor
INA
NBC Protection
Yes
Smoke Equipment
INA
Image Sources
Details
Country of Origin
Saudi Arabia
Category
Mine-Resistant Ambush Protected (MRAP)
Land > Infantry Vehicles > Mine-Resistant Ambush Protected (MRAP)
Filter Label
T
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
6.91 m
Width
2.82 m
Height
2.64 m
Weight
16000 kg
Operators (1)
Saudi Arabia
