Basic Information

Name

NTC VISMOD T-90 Russian Main Battle Tank (MBT)

Designation

NTC VISMOD T-90 Russian Main Battle Tank (MBT)

Alternate Designation

NTC VISMOD T-90 Russian Main Battle Tank (MBT)

Equipment Type

Main Battle Tank (MBT)

Manufacturer

Uralvagonzavod

Date of Introduction

1993

Description

NTC VISMOD T-90 Russian Main Battle Tank (MBT) The T-90 is a third-generation Russian battle tank that entered service in 1993. The tank is a modern variation of the T-72B and incorporates many features found on the T-80U. Originally called the T-72BU, but later renamed to T-90, it is an advanced tank in service with Russian Ground Forces and the Naval Infantry. The T-90 uses a 125 mm 2A46 smoothbore main gun, the 1A45T fire-control system, an upgraded engine, and gunner's thermal sight. Standard protective measures include a blend of steel and composite armor, smoke grenade dischargers.

Ground Specifications

Crew 3

Engine V-12 Diesel (1000 hp)

Active Protection the Shtora-1 countermeasures system

Variants

T-90K Commander's version of the T-90, with additional communication (station R-163-50K) and navigation equipment (TNA-4-3)

T-90A Russian army version with welded turret, V-92S2 engine and ESSA thermal viewer. Sometimes called T-90 Vladimir, in honor of its chief designer Vladimir Potkin

T-90AK Command version of T-90A.

T-90AM Latest version of the T-90A.[77] The main features include the modernisation of the old turret design, which is equipped with a new advanced fire control system "Kalina" (with integrated combat information and control systems), a new automatic loader and a new upgraded gun 2A46M-5, as well as a remote-controlled anti-aircraft gun "UDP T05BV-1". The new version also includes the Relikt (Ð ÐµÐ»Ð¸ÐºÑ (Ð´Ð¸Ð½Ð°Ð¼Ð¸ÑÐµÑÐºÐ°Ñ Ð·Ð°ÑÐ¸ÑÐ°) ERA bricks instead of the Kontakt-5 ERA bricks.

Ð¢-90M New modernized version of Ð¢-90Ð. It's a program of modernization of Vladimir tanks and will include 400 tanks currently in service. Tanks will receive 2Ð82-1Ð gun (same as in T-14) and fire control system Kalina. They will be upgraded with Afghanit APS and Relikt ERA. The upgrades are also aimed at improving network-centric warfare capabilities and coordination with Armata project vehicles. The first contract was signed in 2017 and serial production started in 2018.

T-90S Export version of the T-90, later adopted by the Russian Armed Forces as the T-90A. These tanks were made by Uralvagonzavod and were updated with 1,000 hp (750 kW) engines made by Chelyabinsk Tractor Plant. These tanks carry a leaner version of the Shtora-1 passive/active protection system which lacks the infra-red dazzlers carried on the turret. Sometimes called T-90C (Cyrillic letter es looks like a Latin c). These were initially supplied with cast turrets of the early T-90, and when stocks were depleted, new, welded turrets were fabricated.

T-90SK Commander's version of the T-90S, with additional communication and navigation equipment. It differs in radio and navigation equipment and Ainet remote-detonation system for HEF rounds.

T-90S "Bhishma" â modified T-90S in Indian service.

T-90MS Also known as T-90SM is an updated version of the T-90S. It is equipped with a 1,130 hp engine, a PNM Sosna-U gunner view. a UDP T05BV-1 RWS with a 7.62 mm machine gun, GLONASS, inertial navigation systems, new Relikt explosive reactive armour (ERA) that covers more of the tank, and a steering wheel. A new removable turret bustle is included, which provides storage for eight additional rounds. The T-90MS is ready for serial production.[88] 4 video cameras provide a 360Â° view of the environment, while the tank is more connected to command. The T-90MS has an upgraded thermal imager that can detect tanks over 3300 meters away.

BREM-1M Armoured recovery vehicle.

IMR-3M Combat engineer vehicle.

MTU-90 Bridge layer tank with MLC50 bridge.

BMR-3M Mine clearing vehicle.

MTU-2020 Bridge layer tank based on the T-90A whose chassis has been extended, along with the addition of a road wheel.

System

Alternative Designation NTC VISMOD T-90 Russian Main Battle Tank (MBT)

Type Main Battle Tank

Family T-90 Family of Main Battle Tanks

Manufacturer Uralvagonzavod

Mission Type Operates in all three zones and is the primary system for Armor Troops comprising MiBNs

Crew 3x Crew Members (Commander, Driver, and Gunner)

Range Max Speed: 67km/h; Main Armament: 125mm Cannon; Rate of Fire per min: 5-8x Rounds; Maximum Effective Range: 2,500m â3,000m (MILES); Secondary Armament: 7.62mm, Coax MG (2,000x); Thermals: Night (2,000m) and regular Day sights (4,000m)

Effects Inflicts 630mm armor penetration at 2000mwith APFSDS-T, can fire APFSDS-T, HEAT,HE-Shrapnel, HE-T andAT-11B/ATGM has 900mm armor penetration.

Targeting Movement and Maneuver assets.

Vulnerability Direct Fire Engagement by Tanks,Javelins, ATGMs, and HIMARS.

CBI 3x MBTs in1x MIC, 6x MBTs in 1x MiBN, 3x MiBNs in a BTG, and composition changes based on rotational design.

Dimensions

Length 9.63 m

Width 3.78 m

Height 2.2 m

Weight, Combat 46 tons

Ground Pressure INA

Automotive

Engine Name V-92S2

Engine Type V-12 Diesel

Engine Power 1,000 hp

Power to Weight Ratio 18.2 hp/tons

Fuel Capacity 1,200 liters

Auxiliary Power Unit Yes

Gas Turbocharger Yes

Transmission Mechanical

Cruising Range 550 km

Speed, Maximum Road 60 km/h

Speed Maximum Swim Not Amphibious

Speed, Average Cross 50 km/h

Suspension Torsion bar

Gradient 60 %

Side Slope 40 %

Vertical Step 0.8 m

Trench 2.85 m

Fording Depth (No Preparation) 1.2 m

Fording Depth (With Preparation) 5 m

Communications

R-168-100U

Name R-168-100U

Family AKVEDUK R-168 Series

Type VHF

Frequency 30-108 MHz

Capabilities FH, Voice, Data

Range 30-60 km

Mount Vehicle

Status In Service

Echelon DIV, BDE, BN

Automated Control Communication Yes

Main Gun

System

Name 1 x 2A46M

Type 125 mm Smoothbore Gun

In Service 1970 to present

Weight (2A46 125mm Gun) 2,675 kg

Length (2A46 125mm Gun) 6,350 mm

Max Rate of Fire (Autoloader) 7 rds/min

Max Rate of Fire (Manaul) 2-3 rds/min

Sustain Rate of Fire 5-7 rds/min

Range Finder Type INA

Maximum Elevation +14 deg

Minimum Elevation -6 deg

Traverse Range 360 deg

Loader Type Carousel-type autoloader

Minimum Cycle time for the Autoloader 6.5 seconds

Thermal Sleeve Light Allow

Bore Evacuator Yes

Breech Type semi-automatic horizontal sliding breech block via an interrupted screw thread

Breech Maximum Chamber Pressure 6,500 bar over the 5,100 bar

Max Cycle time for a Round 180deg from the Start Position 15 seconds

Carousel Reloading Time 15 min

Ammunition (Option 1)

Type 3BM42M/3BM44M, 125mm Armour-piercing fin-stabilized discarding sabot (APFSDS)

Caliber 125 mm

Muzzle Velocity 125 m/s

Effective Range (Day) 2,000-3,000 m

Effective Range (Night) 2,000-2,600 m

Armor Penetration Yes, 590-630mm at a range of 2000m

Shell Weight 20.4 kg

Projectile Weight 7.5 kg

Charge Weight 5.3 kg

Penetration 270/60 mm/deg

Basic Load 44 Total rounds of any combination of 125mm Projectiles

Ammunition (Option 2)

Type 3BM9/3BM10, 125mm Armour-piercing discarding sabot (APDS)

Caliber 125 mm

Muzzle Velocity 1,715-1,800 m/s

Effective Firing Range 3,000 m

Shell Weight 19.6 kg

Projectile Weight 5.67 kg

Charge Weight 5 kg

Penetration 140/60 mm/deg

Basic Load 44 Total rounds of any combination of 125mm Projectiles

Ammunition (Option 3)

Type 3BK12M, 125mm (HEAT)

Caliber 125 mm

Muzzle Velocity 905-950 m/s

Effective Firing Range 4,000 m

Shell Weight 29 kg

Projectile Weight 19 kg

Charge Weight 5 kg

Penetration 220/60 mm/deg

Basic Load 44 Total rounds of any combination of 125mm Projectiles

Ammunition (Option 4)

Type 3OF19, 125mm (HE)

Caliber 125 mm

Muzzle Velocity 760 m/s

Effective Firing Range 4,000 m

Shell Weight 33 kg

Projectile Weight 23 kg

Charge Weight 5.0 kg

Penetration INA mm/deg

Basic Load 44 Total rounds of any combination of 125mm Projectiles

Anti-Tank Guided Missile

System

Name 9M119 Svir, 9M119M Refleks(NATO designation AT-11 Sniper-B)

Type Laser Beam Anti-Tank Guided Missiles

In Service 1980's to present

Manufacturer Degtyarev plant

Variants 9M119M

Guidance System Laser Beam Riding

Mass 17.2 kg

Diameter 125 mm

Warhead Type Tandem hollow-charge

Warhead Weight 4.5 kg

Max Rate of Fire INA

Operational Range 4,000-5,000 m

Speed Subsonic

Basic Load 6 ea

Tank Commander's Weapon System

System

Name 1 x 12.7mm Kord Heavy Machine Gun,

Type Heavy Machine Gun

Caliber 12.7mm

Manufacturer V.A. Degtyarev Plant

In Service 1998-Present

Weight 25.5 kg

Length 1,980 mm

Max Rate of Fire 650-750 rds/min

Sustain Rate of Fire 550-600 rds/min

Action Gas-operated, rotating bolt

Feed System 50-round linked belt

Sights Iron Sights

Variants 6P50-1, 6P50-2, 6P50-3, 6P49

Ammunition

Type Rifle

Caliber 12.7mm

Cartridge 12.7Ã108mm

Muzzle Velocity 860 m/s

Effective Range 2,000 m

Basic Load 300 ea

Loader's Weapon System

System

Name 1 x 7.62mm PK (Kalashnikov's Machine Gun)

Type General-Purpose Machine Gun

Caliber 7.62mm

Function In use as a front-line infantry and vehicle-mounted weapon with Russia's armed forces.

In Service 1961-present

Manufacturer Degtyaryov plant

Proliferation 1 Million +

Max Rate of Fire 650 rds/min

Sustain Rate of Fire 500 rds/min

Range Finder Type INA

Weight (Gun Only) 9 kg

Weight (Tripod Only) 7.7 kg

Length (Total) 1,203 mm

Length (Barrel) 605 mm

Action Gas-operated, open bolt

Feed System Non-disintegrating metal 50 round belts in 100 and 200/250 round ammunition boxes

Sights Tangent iron sights (default); Optical, Night-vision, Thermal and Radar sights

Ammunition

Type Rifle

Caliber 7.62 mm

Cartridge 7.62Ã54mm

Muzzle Velocity 825 m/s

Effective Range (Iron Sights) 1,000 m

Effective Range (With Sight Adjustments) 100-1,500 m

Maximum Firing Range 3,800 m

Basic Load 1,500 ea

Fire Control

Name INA

Computerized FCS Yes

Thermal Sight Tank Commander No

Thermal Sight Gunner No

Panoramic Commander's Sight No

Main Gun Stabilization Yes, 2E42-4 Zhasmin System

Note The Fire Control System is outdated and is from the late 1990s.

Protection

Hull Armor Steel-composite-reactive blend APFSDS: 550 mm + 250â280 mm with Kontakt-5 = 800â830 mm HEAT: 650â850 mm + 500â700 mm with Kontakt-5 = 1,150â1,550 mm

Turret Armor Steel-composite-reactive blend APFSDS: 550 mm + 250â280 mm with Kontakt-5 = 800â830 mm HEAT: 650â850 mm + 500â700 mm with Kontakt-5 = 1,150â1,550 mm

Applique Armor Available

Explosive Reactive Armor Yes, Kontakt-5 explosive reactive armor blocks, equivalent to up to 500mm of steel armor

Active Protection System Yes, the Shtora-1 countermeasures system

Mine Clearing INA

Self-Entrenching Blade Yes

NBC Protection Yes, GO-27 PRKhR radiation and chemical agent detection system.

Deep Wading Kit Available

Jammer Yes, TShU1-7 IR jammers located either side of the main gun

Laser Radiation Sensors Yes

IR dazzlers Yes

Nakidka Signal Reduction Kit Available

Smoke Equipment Yes, banks of 81 mm Toucha 902B grenade launchers that fire the ZD-6 smoke grenade.

Grenade Maximum Range 250-300 m

Smoke Screen 30 m wide and 10 m high for 60 seconds per grenade.

Fire Suppression System Yes, the Raduga-2 fire-suppression system
