ALPAGUT Turkish Unmanned Aerial Vehicle (UAV)

ALPAGUT

Tactical Unmanned Aerial Vehicle (UAV)
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
ALPAGUT Turkish Unmanned Aerial Vehicle (UAV)
Designation
ALPAGUT
Alternate Designation
ALPAGUT
Equipment Type
Tactical Unmanned Aerial Vehicle (UAV)
Manufacturer
STM
Date of Introduction
2023
Description

The ALPAGUT Turkish Unmanned Aerial Vehicle (UAV) operates effectively both day and night, targeting mobile and stationary land and sea targets, as well as radar and communication systems, critical facilities, personnel, and other opportunities. ALPAGUT can be deployed in both single and swarm configurations, with an operational radius of 60 kilometers and a flight duration of over 60 minutes. It is compatible with various types of warheads. Once launched, the system enters target detection, tracking, and evaluation mode. It hovers in the air while the onboard TV/IIR seeker provides real-time video feeds to the operator. ALPAGUT attacks the identified target autonomously after receiving user approval from the ground. The UAV can detect and recognize targets with its dual-mode seeker without being noticed or affected by jamming systems. A guidance-control system on board allows for precise targeting. Additionally, ALPAGUT offers significant benefits through its fire-and-forget capability and its rapid integration into manned and unmanned land, air, and sea vehicles.

Air & Air Defense Specifications
Max Speed 80.0 km/h
Range 60.0 km
Endurance 60.00 hrs
Wingspan 3.00 m
Payload Capacity 11 kg
System
Alternate Designation ALPAGUT
Type Unmanned Aerial Vehicle (UAV)
Manufacturer STM
Payload Capacity 11 kg High Explosive Blast Fragmentation, Armor Piercing and Thermobaric Warhead options.
Target Set Mobile and Stationary Air Defense Systems, Radar or Communication Systems, Command Centers, Light Armored Land Vehicles, etc.
Integrated Air Platforms MALE and HALE class UAVs, Fixed wing aircraft, attack and general purpose helicopters (i.e. AKINCI, TB-3, AKSUNGUR, ANKA, Hürkuş, ATAK-2, GÖKBEY)
Integrated Land Platforms Land Vehicles, Unmanned Land Vehicles
Integrated Naval Platforms Surface Vessels, Unmanned Sea Vehicles
Dimensions
Length 2.6 m
Height INA
Wingspan 3.0 m
Maximum Takeoff Weight 45 kg
Automotive
Engine Name INA
Engine Type INA
Engine Power INA
Maximum Speed 80 km/h
Cruise Speed INA
Maximum Range 60 km
Service Ceiling INA
Endurance 60 min
Details
Country of Origin Turkey
Category UAVs
Air > UAVs
Filter Label
A
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
2.6 m
Width
3 m
Height
Weight
45 kg
Operators (1)
Turkey
