PC130-8 Japanese Medium Size Hydraulic Excavator
Komatsu PC130-8
Excavators
Other
Basic Information
Name
PC130-8 Japanese Medium Size Hydraulic Excavator
Designation
Komatsu PC130-8
Alternate Designation
Komatsu PC130-8
Equipment Type
Excavators
Manufacturer
—
Date of Introduction
2018
Description
The PC130-8 excavator is equipped with five working modes (P, E, L, B and ATT mode). Each mode is designed to match engine speed and pump speed with the current application. This provides the flexibility to match equipment performance to the job at hand.
Ground Specifications
Crew
1
Variants
Note
There are numerous variants of the PC130. You can view all Komatsu equipment at the following website:
https://www.komatsuamerica.com/
System
Alternative Designation
Komatsu PC130-8
Type
Exavators
Crew
1 ea
Dimensions
Shipping Length Of Unit
7590mm
Shipping Height Of Unit
2875mm
Max Cutting Height
8650mm
Max Loading Height
6210mm
Max Reach Along Ground
8170mm
Max Vertical Wall Digging Depth
4980mm
Max Digging Depth
5520mm
Boom/Stick Option (Hex) 1
One-piece boom 4600mm 15\'1\"/ Arm 2500mm 8\'2\"
Ground Clearance
400mm
Height To Top Of Cab
2855mm
Width To Outside Of Tracks
2590mm
Length Of Track On Ground
2880mm
Tail Swing Radius
2190mm
Removal Counterweight Clearance
895mm
Track Gauge
1990mm
Shoe Size
600mm
Operating Weight
12560kg
Automotive
Engine Name
SAA4D95LE-5
Engine Make
2238
Number Of Cylinders
4
Net Power
68kw
Gross Power
72kw
Power Measured
2200rpm
Displacement
3.3L
Aspiration
Turbocharged, air-to-air aftercooled
Drawbar Pull
123kN
Number Of Carrier Rollers Per Side
1
Number Of Shoes Per Side
43
Number Of Track Rollers Per Side
7
Ground Pressure
32.62kPa
Fuel Capacity
247L
Operating Voltage
24V
Hydraulic System Relief Valve Pressure
34818.5kPa
Hydraulic Pump Flow Capacity
242L/min
Swing Mechanism
Swing Speed
11rpm
Buckets
Reference Bucket Capacity
0.5m3
Minimum Bucket Capacity
0.2m3
Maximum Bucket Capacity
0.6m3
Image Sources
Notes
https://www.heavy-equipmentmanual.com/products/download-komatsu-pc130-8jpn-crawler-excavator-operation-and-maintenance-manual-sn-80001-up; https://komatsuvscat.com/komatsu-pc130-problem-and-solution/; https://www.lectura-specs.com/en/model/construction-machinery/crawler-excavators-komatsu/pc130-5-14976;
Details
Country of Origin
Japan
Category
Land
Land
Filter Label
P
Classification
Domain
Ground
Equipment Status
Active
Operators (3)
United States
Japan
Australia
