NSG-85/CS/LR19 Chinese 7.62mm Sniper Rifle
NSG-85/CS/LR19
Sniper Rifle
Other
Basic Information
Name
NSG-85/CS/LR19 Chinese 7.62mm Sniper Rifle
Designation
NSG-85/CS/LR19
Alternate Designation
NSG-85/CS/LR19
Equipment Type
Sniper Rifle
Manufacturer
NORINCO
Date of Introduction
2014
Description
The NSG-85/CS/LR19 Chinese 7.62mm Sniper Rifle is manufactured in China and is offered internationally through the state-owned NORINCO corporation. This rifle, which is known by two separate names (NORINCO NSG-85 or NORINCO CS/LR19) is an upgraded version of the Chinese Type 85 sniper rifle, which in turn is a copy of the Russian Dragunov SVD rifle. Retaining the same basic layout and design features of the SVD, NORINCO NSG-85 features several improvements such as heavier, cold-hammer-forged and free-floating barrel, redesigned stocks made from polymer, and a revised receiver which allows the use of the top-mounted Picatinny rail instead of the side-mounted dovetailed rail found on original Dragunov SVD rifles.
Variants
Type 79/85 (SVD) Chinese 7.62mm Sniper Rifle
The Type 79/85 (SVD) Chinese 7.62mm Sniper Rifle is a chambered self‐loading sniper/marksman rifle, which is a direct copy of the Russian SVD.
EM351
The EM351 variant is the 7.62 × 54R chambered copy of the Type 79/85 offered by the Jianshe Industry (Group) Co Ltd for commercial purposes.
EM352
This model, which is indistinguishable from the military model, is offered for commercial sales.
Nakhjir
Nakhjir (Iranian local copy).
System
Alternate Designation
NSG-85/CS/LR19
Type
Sniper Rifle
Caliber
7.62 mm
Manufacturer
NORINCO
Action
Gas, short‐stroke piston
Mode of Fire
Semi‐auto only
Muzzle Velocity
831 m/s
Maximum Effective Range
800 m
Feed
Detachable, box magazine
Magazine
10 rounds
Sighting
No iron sights are fitted. However, the weapon features a length of Picatinny-like rail on the top of the receiver. The rail‐mounted sights are selected by the user.
Note #1
The barrel is not fitted with a muzzle device, nor is it fitted with a foresight mount.
Note #2
For accuracy, the barrel is threaded on the outer rear end and screwed directly to the milled receiverʼs inner forward end.
Dimensions
Length
1,225 mm
Barrel Length
620 mm
Weight, Empty
4.25 kg
Ammunition
Type
Rifle
Caliber
7.62mm
Cartridge
7.62 × 54mmR
Basic Load
10 Rounds per magazine
Details
Country of Origin
China
Category
Sniper Rifles
Land > Infantry Weapons > Sniper Rifles
Filter Label
N
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
1.23 m
Width
—
Height
—
Weight
4.25 kg
Operators (2)
China
Bangladesh
