Vuran 4X4 MPAV Turkish 4x4 Mine-Resistant Ambush Protected (MRAP)

Vuran 4x4 MPAV

Mine-Resistant Ambush Protected (MRAP)
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
Vuran 4X4 MPAV Turkish 4x4 Mine-Resistant Ambush Protected (MRAP)
Designation
Vuran 4x4 MPAV
Alternate Designation
Vuran 4x4 MPAV
Equipment Type
Mine-Resistant Ambush Protected (MRAP)
Manufacturer
BMC
Date of Introduction
2015
Description

The Vuran 4X4 MPAV (Mine-Resistant Ambush Protected) is a new combat vehicle developed in Turkey for multiple roles, including patrolling, surveillance, weapon transport, and security operations. It was designed to meet the needs of the Turkish Police as part of a contract with the General Directorate of Security under the Ministry of Internal Affairs of the Republic of Turkey. The Vuran MPAV offers a high level of protection against both mine and ballistic threats. Its features include a monocoque armored cabin, armored windows, shock-absorbing seats, a V-shaped underbelly, gun ports, and an emergency exit hatch. As part of a family of multi-purpose armored vehicles, the Vuran 4X4 ensures the safety of its passengers from mines and ballistic attacks. Notable features include front and rear view cameras, an automatic fire extinguishing system, a remote-controlled weapon station, run-flat tire inserts, and a heating and cooling air conditioning system. The BMC Vuran can be equipped with various enhancements such as a remote-controlled automatic weapon station, an automatic fire suppression system, air conditioning, and a run-flat tire system. With its powerful engine, automatic transmission, and independent suspension system, along with compact dimensions, it boasts high mobility. The vehicle can transport up to nine military personnel, including the driver.

Ground Specifications
Crew 2
Mobility Type Wheeled (4x4)
Main Weapon 7.62-mm or 12.7-mm machine gun
Engine Diesel (375 hp)
NBC Protection Yes
Max Speed 110.0 km/h
Range 600.0 km
System
Alternative Designation Vuran 4x4 MPAV
Type Mine-Resistant Ambush Protected (MRAP)
Manufacturer BMC
Configuration 4x4
Crew 2 ea
Passengers 7 ea
Dimensions
Length 6,220 mm
LENGHT (with Spare Tire) 6,810 mm
Width 2,620 mm
Height 2,660 mm
HEIGHT (with RCWS) 3,500 mm
Weight, Combat 19,100 kg
Automotive
Engine Name Cummins ISL e3 375 PS
Engine Type Diesel
Engine Power 375 PS (275 kW) @ 2100 rpm
Maximum Torque 1550 Nm @ 1200 rpm
Maximum Range 600 km
Maximum Speed 110 km/h
Amphibious No
Gradient 60%
Side Slope 30%
Vertical Step INA
Trench INA
Fording 800 mm
Ground Clearance 400 mm
Main Weapon System
Note The vehicle can be equipped with a remote-controlled automatic weapon station, such as the ASELSAN SARP, which can be fitted with a 7.62-mm or 12.7-mm machine gun.
Protection
Armor The V-shape underbody and monocoque allow it to protect the personnel inside from land mines and improvised explosive devices (IEDs). STANAG 4569; Ballistic Protection; Outside RPG Protection (Optional); Mine Protection; Shooter Detection System; IED Protection.
Applique Armor Available
NBC Protection Yes
Smoke Equipment Yes
Details
Country of Origin Turkey
Category Mine-Resistant Ambush Protected (MRAP)
Land > Infantry Vehicles > Mine-Resistant Ambush Protected (MRAP)
Filter Label
V
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
6.22 m
Width
2.62 m
Height
2.66 m
Weight
19100 kg
Operators (8)
Turkey
Bosnia and Herzegovina
El Salvador
Georgia
Kosovo
Libya
Tunisia
Turkmenistan
