Bayonet 350 American Amphibious Unmanned Ground Vehicle (UGV)
Bayonet 350
Unmanned Ground Vehicle (UGV)
Other
Basic Information
Name
Bayonet 350 American Amphibious Unmanned Ground Vehicle (UGV)
Designation
Bayonet 350
Alternate Designation
Bayonet 350
Equipment Type
Unmanned Ground Vehicle (UGV)
Manufacturer
Greensea
Date of Introduction
2024
Description
The Bayonet 350 American Amphibious Unmanned Ground Vehicle (UGV) is the largest in the Bayonet class, engineered for the heaviest payloads and the harshest environmental conditions. It's scalable architecture allows the chassis to be customized to specific payload requirements, making it an ideal the choice for missions demanding significant capacity and robust performance. Whether for complex scientific research, extensive military operations or challenging commercial tasks, the Bayonet 350 is equipped to deliver unparalleled results
Ground Specifications
Mobility Type
Track
Engine
Battery
Amphibious
Yes
Range
14.8 km
System
Alternative Designation
Bayonet 350
Type
Amphibious Unmanned Ground Vehicle (UGV)
Manufacturer
Greensea
Configuration
Track
Crew
Unmanned
Deck Capacity
2WD: 136.1 kg continuous, 281.3 kg peak
AWD: 517.1 kg continuous, 793.8 kg peak
Sensor Packages
Standard: Depth Sensor - Keller Scientific; Camera - Sidus SS400IP; Forward Looking Sonar - Oculus 750, 1200; GPS - Ublox / Advanced Navigation; IP Radio - 70Mbs (approximate), LOS 100 meters
Optional: ACOMMS - Benthos, Oceancomm; RTK GPS - Trimble R12; DVL - Nortek
Dimensions
Length
152.4 cm
Width
182.88 cm
Height
35.56 cm
Open Deck Space
139.7 cm x 71.12 cm
Weight, with Batteries
2WD: 272.2 kg
AWD: 326.6 kg
Automotive
Engine Name
INA
Engine Type
Battery
Engine Capacity
24VDC, 250 Watts
Maximum Range
14.8 km
Maximum Speed
INA
Amphibious
Yes
Maximum Depth
100 m
Endurance
6 hours
Protection
Armor
INA
Image Sources
Notes
https://euro-sd.com/2025/02/major-news/42416/greensea-bayonet-250-for-leon/; https://www.oceansciencetechnology.com/company/greensea-iq/bayonet-250/; https://www.unmannedsystemstechnology.com/company/greensea-iq/bayonet-250-amphibious-crawler/; https://greenseaiq.com/wp-content/uploads/2024/05/data_product_sheet_bayonet250_v2-copy.pdf
Details
Country of Origin
United States
Category
Unmanned Ground Vehicles (UGV)
Land > Unmanned Ground Vehicles (UGV)
Filter Label
B
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
1.52 m
Width
1.83 m
Height
0.36 m
Weight
2 kg
Operators (1)
United States
