Patria TRACKX Finnish Tracked Amphibious Armored Personnel Carrier (APC)
Patria TRACKX
Amphibious Armored Personnel Carrier (APC)
Other
Basic Information
Name
Patria TRACKX Finnish Tracked Amphibious Armored Personnel Carrier (APC)
Designation
Patria TRACKX
Alternate Designation
Patria TRACKX
Equipment Type
Amphibious Armored Personnel Carrier (APC)
Manufacturer
Patria
Date of Introduction
2025
Description
The Patria TRACKX Finnish Tracked Amphibious Armored Personnel Carrier (APC) is designed to conquer the most challenging environments with ease. Designed to survive extreme conditions, the focus has been on optimizing everything. This vehicle has undergone extensive trials over the past few years on snow, muddy soils, forests, and road networks. Key guidelines include exceptional wide rubber tracks, a low, centrally located center of gravity and independent, adjustable hydropneumatics suspension for each road wheel, nearly flat bottom without torsion bars.
Ground Specifications
Crew
2
Mobility Type
Tracked
Engine
Diesel, 7-liter inline 6-cylinder (361 hp)
Amphibious
Yes
Max Speed
80.0 km/h
Range
550.0 km
System
Alternative Designation
Patria TRACKX
Type
Amphibious Armored Personnel Carrier (APC)
Manufacturer
Patria
Configuration
Track
Crew
2 ea
Passengers
10 ea
Payload Capacity
3.5 tons
Operating Temperature
−46°C to +44°C
Dimensions
Length
7.2 m
Width
2.9 m
Height
2.0 m
Weight, Empty
11.5 tons
Weight, Combat
15.5 tons
Automotive
Engine Name
Caterpillar 7.1
Engine Type
Diesel, 7-litre inline 6-cylinder
Engine Power
361 hp
Transmission
Renk HSWL076 automatic
Maximum Range
550 km
Maximum Speed
80 km/h
Amphibious
Yes
Amphibious Speed
4 km/h
Gradient
60%
Side Slope
INA
Vertical Step
INA
Trench
2.0 m
Ground Clearance
0.55 m (adjustable)
Main Weapon System
Note
KNDS France 20 M 621 20mm cannon on SIMA Innovation RM-750 ring mount. 12.7mm HMG + 7.62mm MG on ring mount + drone jammer.
Protection
Armor
STANAG 4569 Level 1 ballistic and Level 1 mine. Blast-attenuating seats standard. Flat underside facilitates blast mat integration.
Applique Armor
Option for Level 2 ballistic (at cost of payload)
NBC Protection
Optional
Smoke Equipment
INA
Details
Country of Origin
Finland
Category
Land
Land
Filter Label
P
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
7.2 m
Width
2.9 m
Height
2 m
Weight
15500 kg
Operators (1)
Finland
