RBS-15 Swedish Long-Range Anti-Ship Missile

RBS-15

Spotted an error? Sign in to suggest an edit.
Basic Information
Name
RBS-15 Swedish Long-Range Anti-Ship Missile
Designation
RBS-15
Alternate Designation
Equipment Type
Manufacturer
Date of Introduction
1985
Description

The RBS-15 (Robotsystem 15) is a long-range fire-and-forget surface-to-surface and air-to-surface, anti-ship missile. The later version Mk. III has the ability to attack land targets as well. The missile was developed by the Swedish company Saab Bofors Dynamics. The missile was developed from the RB 04 missile that was used by the Swedish air force. The front of the missile was retained, including the warhead, but the rear received new wings and a turbofan engine replaced the rocket previously used. The RBS-15 underwent trials on the missile FAC HMS Piteå from 1983 and became operational with the Swedish Navy in 1985. The Västergötland class submarines were to have 4 vertical missile launch tubes for RBS-15 missiles in an extended hull, canceled due to budget constraints and to not fitting the way Swedish submarines operated. In March 2017 Saab received an order for a new generation anti-ship missile to replace the RBS-15. The order is valued at 3.2 billion SEK and deliveries will take place between 2017–26. The new missile will have better range, a better seeker and lower weight. It will have the ability to knock out a wide range of sea and land targets, all-weather capability and a design that allows for future upgrades.

Variants
RBS-15 Mk. I Powered by a French Microturbo TRI-60 engine, with a thrust of 3.73 kN (380 khp/830 lbf). Range 70+ km
RBS-15F An Mk. I adapted for air launch. Entered service in 1989.
RBS-15 Mk. II Range 70+ km. Designed to be launched from a number of different platforms, such as land-based launchers, aircraft, and ships.
RBS-15SF Mk. II version for Finland. Local designation MTO 85 (Meritorjuntaohjus 1985)
RBS-15 Mk. III Range over 200 km, with land attack capability. New warhead (increased penetration and insensitive munitions qualification) from TDW. There is only a ship launched version. Production started in 2004. New oval launch tubes instead of the old box type.
RBS-15F ER Aircraft launched version of the Mk. III
RBS-15SF-3 Both new Mk. IIIs and upgraded Mk. IIs, which have been upgraded to Mk. III standard. Finnish designation MTO 85M
RB-15 Mk. III+ & RB 15 F-ER Ordered in March 2017 by Sweden. Will have better range, a better seeker and lower weight. It will have the ability to knock out a wide range of sea and land targets, all-weather capability and a design that allows for future upgrades. To be carried by Visby-class corvettes and JAS Gripen E. Will be delivered between 2017-2026 and fully operational in the mid 2020s.
RBS-15 Missile
System
Name RBS-15
Type Long-Range Fire-and-Forget Surface-to-Surface and Ar-to-Surface, Anti-Ship Missile.
Manufacturer Saab Bofors Dynamics, Diehl BGT Defence
Length 4.33 m
Diameter 50 cm
Wingspan 1.4 m
Warhead 200 kg HE blast and pre-fragmented warhead.
Detonation Mechanism impact or proximity
Engine Turbojet
Operational Range 70 km for RBS-15 Mk. I and II, 250 km for RBS-15 Mk. III, 300+km for RBS-15 MkV
Flight Altitude Sea skimming
Speed Subsonic
Guidance System inertial, GPS, terminal active radar homing (J band)
Launch Platform naval ships, aircraft and land-based missile launchers
Details
Country of Origin Sweden
Category Anti-Ship Missiles
Air > Anti-Ship Missiles
Filter Label
R
Classification
Domain
Air & Air Defense
Equipment Status
Active
Operators (7)
Germany
Poland
Sweden
Algeria
Croatia
Finland
Thailand
