Dozer-B Ukrainian 4x4 Armored Personnel Carrier (APC)
Dozer-B
Amphibious Armored Personnel Carrier (APC)
Other
Basic Information
Name
Dozer-B Ukrainian 4x4 Armored Personnel Carrier (APC)
Designation
Dozer-B
Alternate Designation
Dozer-B
Equipment Type
Amphibious Armored Personnel Carrier (APC)
Manufacturer
Kharkiv Morozov Machine-Building Design Bureau (KMDB)
Date of Introduction
2007
Description
The Dozer-B Ukrainian 4x4 Armored Personnel Carrier (APC) is privately developed by Kharkiv Morozov Machine-Building Design Bureau (KMDB) in Ukraine. This tactical utility vehicle can carry three crew members and eight troops.
Ground Specifications
Crew
3
Mobility Type
Wheeled (4x4)
Main Weapon
12.7mm NSBT-12.7 machine gun
Engine
Diesel (112 hp)
NBC Protection
Yes
Max Speed
120.0 km/h
Range
700.0 km
Variants
Dozor-A
Unarmored off-road general purpose vehicle.
Oncilla
Polish produced version.
Mission Variants
The 4×4 variant is designed to suit a variety of missions. It can be used as an ambulance, a command vehicle, a patrol vehicle and a nuclear, biological and chemical (NBC) reconnaissance vessel.
System
Alternative Designation
Dozer-B
Type
Armored Personnel Carrier (APC)
Manufacturer
Kharkiv Morozov Machine-Building Design Bureau (KMDB)
Configuration
4x4
Crew
3 ea
Passengers
8 ea
Winch
WARN XD 9000i winch for self recovery.
Satellite Navigation System
The GPS NAVSTAR and GLONASS satellite navigation systems determine the location and speed of the vehicle.
Dimensions
Length
5.4 m
Width
2.4 m
Height
2.28
Weight, Combat
7.3 tons
Automotive
Engine Name
The Dozor B is powered by a single 112hp or 136hp or 197hp turbocharged intercooled diesel engine. It can use either of the four-stroke, four-cylinder engines the DEUTZ BF 4M 1013 FC and IVECO 8142.38.11.
Engine Type
Diesel
Engine Power
112hp or 136hp or 197hp turbocharged intercooled diesel engine.
Maximum Range
700 km
Maximum Speed
120 km/h
Amphibious
No
Gradient
60%
Side Slope
40%
Vertical Step
0.4 m
Trench
0.5 m
Fording
1.0 m
Communications
External Communication System
The external communication devices include an R-173M radio set and an R-173PM radio receiver with an operating frequency range of 30,000kHz-75,999kHz. The radio communication range in rugged terrains is 20km.
Internal Communications System
Internal communication is via an AVSK-1 crew intercom system.
Main Weapon System
Note
The Dozor-B is armed with a remote controlled 12.7mm NSBT-12.7 machine gun with a PZU-7 optical monocular periscopic sight.
It has an ammunition capacity of 450 rounds. It can fire within an elevation range of – 3° to +68°. The roof-mounted anti-aircraft machine gun can be rotated 360°.
Protection
Armor
The Dozor-B is designed for protection against anti-tank mines and small arms fire. It has an armored hull for protection of the crew and internal equipment against 7.62mm bullets. The cylindrical armored steel bottom provides protection against mines. The windows of the APC are also armored to the level of the main armor. The armored glass windows provide clear vision during the day. Night driving aids can be installed during poor visibility.
Applique Armor
Additional protection against powerful mines and larger calibre bullets can be achieved by installing additional removable protection components to the hull. The ventilating and filtering unit purifies the air in the compartments for protection against NBC attacks. Dazzle paint also reduces the detection range of the vehicle.
NBC Protection
Yes
Smoke Equipment
INA
Details
Country of Origin
Ukraine
Category
Land
Land
Filter Label
D
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
5.4 m
Width
2.4 m
Height
2.28 m
Weight
7300 kg
Operators (3)
Ukraine
Poland
Senegal
