UAZ-452V Russian 4x4 Convertible Van Wagon

UAZ-452V

Convertible Van Wagon
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
UAZ-452V Russian 4x4 Convertible Van Wagon
Designation
UAZ-452V
Alternate Designation
UAZ-452V
Equipment Type
Convertible Van Wagon
Manufacturer
Ulyanovsk Automobile Plant
Date of Introduction
1965
Description

UAZ-452V – Convertible Van Wagon. The UAZ-452 is a family of off-road vans produced at the Ulyanovsk Automobile Plant (UAZ) since 1965. Its predecessor model UAZ-450 (produced between 1958-1966) was based on the chassis and engine of the four-wheel drive light truck GAZ-69, and was the first "forward control" vehicle of this type to be built in the Soviet Union and Russia. Vehicles produced between 1965–1979 were equipped with old-style lights: turn signal lights were colorless (white), rear lights were round, and the back of the body was rounder. Subsequent post-1979 models got amber (yellow) signal lights, and rear lights were slightly bigger and rectangular. In 1985 the van was upgraded and spun off into separate submodels: 39625, 3962, 3303, 3909 and 2206. The upgrade consisted of lighting fixtures that met modern international requirements, alarms, a new instrument panel, and a new speedometer. The brakes were redesigned. The engine was also upgraded, and its power output increased to 99 hp against the previous 78 hp. In the early 2000s, the model was given new plastic side mirrors taken from the GAZ GAZelle van, headrests on front seats; and new passenger seats for a minibus version (2206) were also given headrests. The pickup truck (version 3303) was fitted with a metal body instead of a wooden one.

Ground Specifications
Crew 1
Mobility Type Wheeled (4x4)
Engine Gasoline (72 hp)
Active Protection None
Max Speed 95.0 km/h
Range 500.0 km
System
Alternative Designation UAZ-452V
Type Convertible Van Wagon
Manufacturer Ulyanovsk Automobile Plant
Configuration 4x4
Family UAZ
Passenger Capacity 10 ea
Crew 1 ea
Note #1 Vehicles produced between 1965–1979 were equipped with old-style lights: turn signal lights were colorless (white), rear lights were round, and the back of the body was rounder. Subsequent post-1979 models got amber (yellow) signal lights, and rear lights were slightly bigger and rectangular.
Note #2 The body of the van is normally equipped with two front doors, a single-wing door on the right side and a double-wing door at the rear, although the exact configuration can vary depending on the specific modification. Notable in the van are the fuel ports on the left and the right side of the van, leading to two separate fuel tanks.
Dimensions
Length 4.36m
Width 1.90 m
Height 2.09 m
Wheelbase 2.30 m
Curb Weight 1,760 kg
Ground Clearance 220 mm
Automotive
Engine Name ZMZ-451M1
Engine Type Petrol
Engine Power 72 hp
Maximum Speed 95 km/h
Range 500 km
Speed Maximum Swim Not Amphibious
Gradient 57 %
Side Slope 30%
Vertical Step 0.3 m
Trench 0.5 m
Fording 0.55 m
Protection
Armor None
Applique Armor No
Active Protection System No
Mine Clearing No
NBC Protection INA
Smoke Equipment No
Details
Country of Origin Russia
Category Transportation
Land > Combat Support Vehicles > Transportation
Filter Label
U
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
4.36 m
Width
1.9 m
Height
2.09 m
Weight
1760 kg
Operators (9)
United Kingdom
Sweden
Denmark
Estonia
Finland
Latvia
Lithuania
Norway
Eastern Europe
