M911 American 8x6 Tank Transporter
M911
Tank Transporter
Other
Basic Information
Name
M911 American 8x6 Tank Transporter
Designation
M911
Alternate Designation
M911
Equipment Type
Tank Transporter
Manufacturer
Oshkosh
Date of Introduction
1977
Description
The M911 American 8x6 Tank Transporter emerged as a supplement for the previous M746 tractor truck, which proved to be expensive to maintain and operate. In 1976 the US Army issued a requirement for a new tank transporter.
Ground Specifications
Crew
2
Engine
12.06 liter, V-8, water cooled, 2 stroke, diesel (450 hp)
Max Speed
72.0 km/h
Range
1344.0 km
System
Alternative Designation
M911
Type
Tank Transporter
Manufacturer
Oshkosh Corporation
Configuration
8x6
Crew
2 ea
5th Wheel Load
20,866 kg
Dimensions
Length
9.373 m
Width
2.896 m
Height
3.404 m
Weight, Unladen
18,144 kg
Weight, Laden
39,463 kg
Gross Combination Weight (GCW)
102,514 kg
Automotive
Engine Name
Detroit Diesel model 8V92TA-90
Engine Type
12.06 liter, V-8, water cooled, 2 stroke, diesel
Engine Power
450 hp at 2,100 rpm, 1,684 N m torque at 1,400 rpm
Fuel Capacity
757 liters
Maximum Range
1,344 km
Maximum Speed
72 km/h
Amphibious
No
Gradient
20%
Fording
0.711 m
Turning Radius
13.72 m
Protection
Armor
INA
Applique Armor
No
NBC Protection
INA
Smoke Equipment
No
Details
Country of Origin
United States
Category
Transportation
Land > Combat Support Vehicles > Transportation
Filter Label
M
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
9.37 m
Width
2.9 m
Height
3.4 m
Weight
39463 kg
Operators (5)
Greece
Morocco
Oman
Saudi Arabia
Thailand
