VA25 Chinese Unmanned Aerial Vehicle (UAV)

VA25

Tactical Unmanned Aerial Vehicle (UAV)
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
VA25 Chinese Unmanned Aerial Vehicle (UAV)
Designation
VA25
Alternate Designation
VA25
Equipment Type
Tactical Unmanned Aerial Vehicle (UAV)
Manufacturer
T-Drones
Date of Introduction
2023
Description

The VA25 Chinese Unmanned Aerial Vehicle (UAV) is a vertical takeoff and landing (VTOL) platform featuring a highly reliable power system and a locking propeller design that significantly extends flight time while enhancing safety and stability. The propellers remain stationary even in strong winds, which improves overall flight efficiency. With an endurance of up to 210 minutes, an IP55 rating, and an average cruising speed of 80-90 km/h, the VA25 is designed for quick assembly and disassembly, allowing setup in just three minutes. The customized T-MOTOR propulsion system ensures higher efficiency and a safer, more reliable flight for extended missions. You can select different payloads based on mission requirements, as the VA25 is compatible with various flight control systems, providing an optional Ready-to-Fly (RTF) experience.

Air & Air Defense Specifications
Engine Electric
Max Speed 120.0 km/h
Cruise Speed 90.0 km/h
Range 150.0 km
Endurance 210.00 hrs
Wingspan 2.50 m
Payload Capacity 2 kg
System
Alternate Designation VA25
Type Unmanned Aerial Vehicle (UAV)
Manufacturer T-Drones
Payload Capacity 2 kg
Frame Material Carbon Fiber Composite PVC
Protection IP55
Recommended Control System PIXHAWK & CUAV
Operating Temperature -15℃-50℃
Dimensions
Length 1.56m(Including Pitot Tube1.62m)
Height INA
Wingspan 2.5 m
Maximum Takeoff Weight 13 kg
Automotive
Engine Name INA
Engine Type T-MOTOR
Engine Power INA
Maximum Speed 120 km/h
Cruise Speed 90 km/h
Maximum Range 150 km
Service Ceiling INA
Endurance 210min(1kg Payload
Wind Resistance Level 6
Details
Country of Origin China
Category UAVs
Air > UAVs
Filter Label
V
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
1.56 m
Width
2.5 m
Height
Weight
13 kg
Operators (1)
China
