DJI FlyCart 100 (FC100) Chinese Unmanned Aerial Vehicle (UAV)
DJI FlyCart 100
Tactical Unmanned Aerial Vehicle (UAV)
Other
Basic Information
Name
DJI FlyCart 100 (FC100) Chinese Unmanned Aerial Vehicle (UAV)
Designation
DJI FlyCart 100
Alternate Designation
DJI FlyCart 100; FC100
Equipment Type
Tactical Unmanned Aerial Vehicle (UAV)
Manufacturer
DJI
Date of Introduction
2025
Description
The DJI FlyCart 100 (FC100) Chinese Unmanned Aerial Vehicle (UAV) is designed to withstand extreme conditions, carry substantial payloads, and operate intelligently in mission-critical scenarios, ranging from emergency rescue to power line construction.
Air & Air Defense Specifications
Engine
Battery
Max Speed
100.0 km/h
Range
12.0 km
Service Ceiling
1500 m
Payload Capacity
80 kg
System
Alternate Designation
DJI FlyCart 100; FC100
Type
Unmanned Aerial Vehicle (UAV)
Manufacturer
DJI
Payload Capacity
The drone supports payloads of up to 80 kilograms when operated with a single battery and 65 kilograms when using two batteries
Sensor Suite
LiDAR, millimeter-wave radar, five-eye fisheye cameras, and night-time lighting. These provide 360-degree awareness, intelligent obstacle avoidance, and real-time terrain sensing. New algorithms help the drone automatically decelerate near the ground, detect pedestrians and vehicles, and adjust altitude to avoid ground collisions.
Lifting System
The FC100 ships with two lifting systems: a flagship hoist system with a 30-meter retractable rope, and a dual-electric version with a 10-meter fixed rope for simpler operations. Features such as auto-anti-sway, real-time weighing, and electric hooks make aerial lifting more precise and safer, even in emergencies. For high-altitude electrical work or emergency food drops, the flagship version allows remote hook release, rope drop in case of entanglement, and wireless charging. Sound and light alerts enhance visibility during night operations.
Parachute System
Adding to its fault tolerance is a dedicated parachute system, capable of deploying at maximum weight from over 100 meters, keeping descent under 6 m/s. It’s the last line of defense designed to protect both cargo and people below.
DJI Delivery App
The new DJI Delivery app simplifies mission planning and real-time flight monitoring. It’s backed by DJI’s Driver cloud platform, which supports fleet management, AR guidance, loading zone detection, and centralized data analysis. The FC100 also supports DJI’s PSDK interface and cloud-to-cloud 2.0 integration, enabling third-party payloads and custom workflows.
Operating Temperature
-20°C to 40°C
Dimensions
Length
INA
Height
INA
Wingspan
INA
Maximum Takeoff Weight
149.9 kg
Automotive
Engine Name
INA
Engine Type
Battery
Engine Power
INA
Charging Time
A single battery supports 9-minute ultra-fast charging, can self-heat in cold weather, and lasts for up to 1,500 cycles.
Maximum Speed
The DJI FlyCart 100 does not have a published maximum speed. However, the related DJI FlyCart 30 has a maximum speed of 20 m/s (72 km/h or 44.7 mph) in manual flight mode. In automatic flight, the FlyCart 30's maximum speed is 15 m/s.
Maximum Range
DJI’s new power system supports both single and dual battery modes. In its max-performance single-battery setup, the FC100 can carry an 80kg payload up to 6km. Using dual batteries, it carries 65kg up to 12km.
Service Ceiling
1,500 m
Maximum Flight Altitude
6,000 m
Wind Resistance
up to 12 m/s
Endurance
INA
Image Sources
Note
https://armyrecognition.com/news/army-news/2025/china-presents-new-dji-fc100-heavy-transport-drone-for-high-altitude-resupply-missions; https://dronedj.com/2025/06/30/new-dji-drone-flycart-100/; https://dronedj.com/2025/06/30/new-dji-drone-flycart-100/; https://dronexl.co/2025/06/30/dji-flycart-100-unveiled-heavy-lift-drone/
Details
Country of Origin
China
Category
UAVs
Air > UAVs
Filter Label
D
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
—
Width
—
Height
—
Weight
149.9 kg
Operators (1)
China
