Dupuy De Lome Class French Intelligence Collection Ship

Dupuy de Lôme (A759)

Intelligence-Collection and Missile-Range Instrumentation Ship
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
Dupuy De Lome Class French Intelligence Collection Ship
Designation
Dupuy de Lôme (A759)
Alternate Designation
Dupuy de Lôme (A759)
Equipment Type
Intelligence-Collection and Missile-Range Instrumentation Ship
Manufacturer
Royal Niestern Sander
Date of Introduction
2006
Description

The Dupuy De Lome Class French Intelligence Collection Ship is named after the 19th century engineer Henri Dupuy de Lôme, is a ship designed for the collection of signals and communications beyond enemy lines, which entered the service of the French Navy in April 2006. In contrast to Bougainville, the ship that she replaced, Dupuy de Lôme was specifically designed for sea intelligence, pursuant to the MINREM project (Moyen Interarmées Naval de Recherche ElectroMagnétique, "Joint Naval Resources for Electromagnetic Research"). Dupuy de Lôme was designed and built by Royal Niestern Sander shipyards in Delfzijl, The Netherlands with yard number 816. The Thales Naval France designed the electromagnetic intellegence part of the vessel. She provides a 350-day-operational availability a year, out of which 240 can be spent at sea. The ship is operated by two naval crews, each composed of thirty-three sailors and another thirty-three technicians, and an optional complement of up to thirty-eight specialists, depending on the mission. The specialised personnel operates under the Direction du renseignement militaire. On 21 June 2015, Dupuy de Lôme entered the Black Sea along with USS Laboon as part of NATO's presence missions following the Annexation of Crimea by the Russian Federation.

Naval & Littoral Specifications
Crew 30
Beam 15.85 m
Draft 4.91 m
System
Alternative Designation Dupuy de Lôme (A759)
Total Built 1 Ship Built
Type Intelligence Collection Ship
Builder France
In Service 2006-Present
Crew 30 total (8 off. + 22 enl.) + 80 technicians
Dimensions
Length 101.75 m
Beam 15.85 m
Draft 4.91 m
Height to Main Deck 7.70 m
Displacement, Full Load 3,600 tons
Displacement, Standard 3,150 tons
Propulsion System
Engine Name 2 x MaK 9M25 diesels
Engine Type Diesel
Engine Power 7,965 total bhp
Maximum Range 3,400 nm at 16 knots
Maximum Speed 16 knots
Endurance 30 days
Communications
Radio 1 x MINREM (HF/VHF/UHF analysis of communications)
Main Weapon System
Quantity 2 x 12.7-mm machine guns
System
Name 2 x M2 Browning
Type Heavy Machine Gun
Caliber 12.7 mm
Length 1,654 mm
Barrel Length 1,143 mm
Weight 38 kg (83.78 lb) 58 kg (127.87 lb) with tripod and T&E (Traverse and Elevation Mechanism)
Action Short recoil-operated
Rate of Fire 450–600 rounds/min
Muzzle Velocity 890 m/s
Maximum Firing Range 7,400 m
Effective Firing Range 1,800 m
Feed System Belt-fed (M2 or M9 links)
Ammunition
Type Rifle
Caliber 12.7 mm
Cartridge .50 BMG (12.7×99mm NATO)
Basic Load 2,000 each
Radar Systems
Navigation Radar 2 x DRBN38A navigation radars
Radar Warning Receiver 1 x ARBR-21 radar warning receiver (D-K bands)
Protection
Active Protection System INA
Decoys INA
Interceptor #1 1 x interceptor-goniometer satellite transmissions
Interceptor #2 1 x Elite interceptor-goniometer transmissions
Interceptor #3 1 x Egide Naval interceptor-goniometer transmissions
NBC Protection Yes
Details
Country of Origin China
Category Naval
Naval
Filter Label
D
Classification
Domain
Naval & Littoral
Equipment Status
Active
Dimensions
Length
101.75 m
Width
15.85 m
Height
Weight
3600000 kg
Operators (2)
China
France
